CPU

CPU Model
Realtek RTD1619B


CPU Quantity
1


CPU Architecture
64-bit


CPU Frequency
4-core 1.7 GHz


Hardware Encryption Engine
Yes

Memory

System Memory
1 GB DDR4 non-ECC


Notes
Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.

Storage

Drive Bays
2


Compatible Drive Type*  (See all supported drives)

• 3.5" SATA HDD


• 2.5" SATA SSD (with optional 2.5" Disk Holder)


Hot Swappable Drive*
-


Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.

External Ports

RJ-45 1GbE LAN Port*
1


USB 3.2 Gen 1 Port*
2


Notes

• This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.


• The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.

File System

Internal Drives

• Btrfs


• EXT4


External Drives

• Btrfs


• EXT4


• EXT3


• FAT


• NTFS


• HFS+


• exFAT


Notes
Btrfs file system is available from DSM 7.2-64570.

Appearance

Size (Height x Width x Depth)
165 mm x 100 mm x 225.5 mm


Weight
0.88 kg

Others

System Fan
92 mm x 92 mm x 1 pcs


Fan Speed Mode

• Full-Speed Mode


• Cool Mode


• Quiet Mode


• Low-power Mode


Brightness Adjustable Front LED Indicators
Yes


Power Recovery
Yes


Noise Level*
18.2 dB(A)


Scheduled Power On / Off
Yes


Wake on LAN / WAN
Yes


Power Supply Unit / Adapter
60 W


AC Input Power Voltage
100V to 240V AC


Power Frequency
50/60 Hz, Single Phase


Power Consumption
16.31 W (Access)
4 W (HDD Hibernation)


British Thermal Unit
55.62 BTU/hr (Access)
13.64 BTU/hr (HDD Hibernation)


Notes

• For more information on how power consumption is measured, refer to  this article .


• Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G. R. A. S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75°C; Humidity: 58.2-61.8%

Temperature

Operating Temperature
0°C to 40°C (32°F to 104°F)


Storage Temperature
-20°C to 60°C (-5°F to 140°F)


Relative Humidity
5% to 95% RH

Certification

• FCC


• CE


• BSMI


• VCCI


• RCM


• UKCA


• EAC


• CCC


• KC

Warranty

2-year hardware warranty, extendable to 4 years with  Extended Warranty Plus


Notes

• Availability varies by region. Before purchasing, please visit the official web pages of  EW201/202  and  Extended Warranty Plus  for a list of eligible regions.


• The warranty period starts from the purchase date as stated on your purchase receipt.   (Learn more)

Environment

RoHS Compliant

Packaging Content

• Main Unit X 1


• Accessory Pack X 1


• AC Power Adapter X 1


• AC Power Cord X 1


• RJ-45 LAN Cable X 1


• Quick Installation Guide X 1

Optional Accessories

• 3.5" SATA HDD:  HAT3300


• Surveillance Device License Pack


• Disk Holder: Type C
